Alpha Series AC Servo Amplifier Descriptions Page 58

Descriptions
2. CONFIGURATION AND ORDERING INFORMATION
B–65162E/03
38
– FSSB interface cables
Category Name Ordering number Cable length Remarks
A66L–6001–0023#L150R0 15cm
Internal optical cables
A66L–6001–0023#L300R0 30cm
(Note 1)
A66L–6001–0026#L1R003 1m
A66L–6001–0026#L5R003 5m
Optional
FSSB inter-
face cables
A66L–6001–0026#L7R003 7m
A66L–6001–0026#L10R03 10m
External optical cables
(Note 2)
A66L–6001–0026#L20R03 20m
A66L–6001–0026#L30R03 30m
A66L–6001–0026#L50R03 50m
NOTE
1 Optical cables for connecting SVMs.
SVM (COP10A) – SVM(COP10B)
2 Optical cables for connecting the CNC and SVM.
CNC (COP10A) – SVM (COP10B)
(10) Breaker, Magnetic contactor, Lightning surge absorber
The circuit breaker and magnetic contactor capacities are determined by the power supply module specifications.
The ordering drawing numbers and specifications of the circuit breakers and magnetic contactors are shown below.
For dimensions, see Sections 8.1.9 and 8.1.10.
When this equipment is to be prepared by the user, it must satisfy the circuit breaker and magnetic contactor
specifications indicated below.
