B–65162E/03

11. OPTION RELATED TO SPINDLE

471

The table lists the parameters related to rigid tapping using the α series

and αC series spindles. For details of these parameters, refer to the

parameter manual and the manual for each CNC.

Parameter No.

FS0

M/T/TT

FS15 FS16

Description

First

spindle

Second

spindle

M/T M/T

M code setting for rigid tapping

(M series)

0256

(T series)

0253

–––

5210

5212

M code for specifying rigid tapping mode

Setting related to the position coder signal

6501#2 6641#2 3001#2 4001#2 Whether to use the position coder signal. (To be set to 1)

6500#0 6640#0 3000#0 4000#0 Spindle and motor rotation direction

6500#2 6640#2 3000#2 4000#2 Position coder mounting direction

0028#7,6

0003#7,6

0064#7,6 5610

3706#1,0

3707#1,0

Gear ratio between the spindle and position coder

(1, 2, 4, 8)

(1 only for the αC series)

6503

#7,6,4

6643

#7,6,4

3003

#7,6,4

4003

#7,6,4

Position coder signal setting

Setting related to arbitrary gear ratios (only for the α series)

6506#7 6646#7 3006#7 4006#7

Setting for rigid tapping that is based on an arbitrary gear ratio

(CMR) on the command side and uses a motor with a built–in

MZ sensor

0063#3 (M series)

0063#6 (T series)

5604#2,1 5200#1

Whether to use the arbitrary gear ratio (CMR) function on the

command side

(M series)

0663

0664

0665

(T series)

0427 to

0430

5703

5771 to

5774

5221

5222

5223

5224

Number of gear teeth on the spindle side when an arbitrary gear

ratio (CMR) is used on the command side

(M series)

0666

0667

0668

(T series)

0431 to

0434

5704

5781 to

5784

5231

5232

5233

5234

Number of gear teeth on the position coder side when an arbi-

trary gear ratio (CMR) is used on the command side

6935

6937

6975

6977

3315

3317

4171

4173

Number of gear teeth on the spindle side when an arbitrary gear

ratio (DMR) is used on the detection side (to be selected by

CTH1A)

6936

6938

6976

6978

3316

3318

4172

4174

Number of gear teeth on the position detector side when an ar-

bitrary gear ratio (DMR) is used on the detection side (to be se-

lected by CTH1A)

Gear ratio data between the spindle and motor

6556 to

6559

6696 to

6699

3056 to

3059

4056 to

4059

Gear ratio data between the spindle and motor (to be selected

by CTH1A and CTH2A)

11.2.5

Parameter List
