Alpha Series AC Servo Amplifier Descriptions Page 32

Descriptions
2. CONFIGURATION AND ORDERING INFORMATION
B–65162E/03
12
Servo amplifier
module
L+
L–
PSM–HV
PSMC–HV SPM–HV SVM–HV
200R
200S,
L1 L2 L3 U V W
UL VL WL
UM VM WM
Power supply
module
Capacitor
module
Servo amplifier
module (2–axes)
(AC400V)
(AC460V)
DC link
Circuit
breaker 1
AC
reactor
Spindle motor
Servo
motor
Servo
motor
Fan
motor
: Basic configuration
: Equipment to be prepared by the user
Lightening surge
protector
(DC600V)
(AC200V)
(AC230V)
3φ
1φ
Control power supply
AC input
Lightning surge
protector
Magnetic
contactor
Circuit
breaker 2
Circuit
breaker 3
3φ
NOTE
1 For the control power supply, single–phase 200VAC is required.
2 Install circuit breakers, a magnetic contactor, and AC reactor.
3 At the power supply inlet of the power magnetics cabinet, install lightning surge protectors
between the lines and between a line and ground to protect the equipment from surge voltages
caused by lightning. For details, see Appendix A.
4 Note that when PSM–75HV is used, the position of the PSMC–HV differs from the above
diagram. For the position of the PSMC–HV, see (5) in Section 5.1.
5 Measures must be taken to detect the operation (trip) of circuit breaker 3.
