E. CABLE LENGTH

B–65162E/03

APPENDIX

604

Detector

Recommended

cable

Cable structure Maximum cable length

M sensor

(pulse generator)

A66L–0001–0368

0.5mm

, 6 conductors (for power supply)

0.18mm

, 5 pairs (for signals)

72m

When one power line is used

MZ sensor, BZ sensor

(built–in sensor)

A66L–0001–0368

0.5mm

, 6 conductors (for power supply)

0.18mm

, 5 pairs (for signals)

50m

When one power line is used

Magnetic sensor

(for orientation)

A66L–0001–0286

0.5mm

, 6 conductors (for power supply)

0.18mm

, 3 pairs (for signals)

25m

When one power line is used

Position coder A66L–0001–0286

0.5mm

, 6 conductors (for power supply)

0.18mm

, 3 pairs (for signals)

When one power line is used

High–resolution mag-

netic pulse coder

A66L–0001–0367

0.18mm

, 10 pairs (for power supply and

signals)

18m

When one power line is used

High–resolution posi-

tion coder

A66L–0001–0367

0.18mm

, 10 pairs (for power supply and

signals)

When one power line is used

When a cable other than one of the recommended cables above is used,

the voltage drop in the cable must be within 0.2 V for a +5 V power supply.

(Tip) Maximum cable length L can be found from the following formula:

L [m]x0.2 [V] n[line]B2BI [A]BR [Ω / m]

n : Number of power lines (number of +5V or +15V lines)

I : Current consumption of the detector

R : Resistance of a wire used for a power line

Detector Current consumption

M sensor (pulse generator) 0.035A

MZ sensor, BZ sensor (built–in sensor) 0.05A

Magnetic sensor (for orientation) 0.1A

Position coder 0.35A

High–resolution magnetic pulse coder 0.15A

High–resolution position coder 0.35A

Check the check board to confirm that the feedback signal waveform of

each detector satisfies the specifications.

E.1

SPINDLE CABLE

LENGTH (WHEN

RECOMMENDED

CABLES ARE USED)
