Alpha Series AC Servo Amplifier Descriptions Page 263

Descriptions

Page of 699

/ 699

B–65162E/03

9.CONNECTION

243

(b) Models α3/3000 to α40/2000, α65/2000 to α150/2000, αC3/3000 to αC22/1500, αM6/3000 to αM40/3000,

and αL6/3000 to αL50/2000

(Note)

(16)

(15)

(14)

(D)

(A)

(S)

(J, K)

(17)

(F)

(G)

(N, T)

(R)

(H)

(4, 5, 6)

(1, 2)

(3)

(7)

*SD

REQ

+5V

*REQ

0VA

+6VA

Shielding

CNC

Motor

Connector :

MR–20LFH (Honda Tsushin Kogyo Co., Ltd.)

Connector used at the cable end:

Refer to FANUC AC SERVO MOTOR α Series

Descriptions B–65142E.

NOTE

For the incremental pulse coder, it is not necessary to connect pins 3 and 7 of the connector

on the CNC side to pins R and S of the connector on the motor side. No problem will result if

they are connected, however. So, a cable for the absolute pulse coder can also be used for

the incremental pulse coder.
