11. OPTION RELATED TO SPINDLE

B–65162E/03

514

(1) Input Signals (DI Signals) PMC to CNC

(a) Signal addresses

#7 #6 #5 #4 #3 #2 #1 #0

First spindle control input signal

RCHA RSLA INTGA SOCNA MCFNA SPSLA *ESPA ARSTA

G230 G226 G071

RCHHGA MFNHGA INCMDA

OVRA

DEFMDA

NRROA ROTAA INDXA

G231 G229 G072

FS0 FS15 FS16

#7 #6 #5 #4 #3 #2 #1 #0

FS0 FS15 FS16

Second spindle control input signals

RCHB RSLB INTGB SOCNB MCFNB SPSLB *ESPB ARSTB

G234 G234 G075

RCHHGB MFNHGB INCMDB

OVRB

DEFMDB

NRROB ROTAB INDXB

G235 G237 G076

(b) Switching request signal (SPSLA)

[Function] It is used as an instruction signal which selects the spindle motor.

0 : The main spindle motor is selected.

1 : The sub spindle motor is selected.

[Usage] This signal is changed after stopping the spindle motor.

Speed zero signal (SSTA) is used for confirming that a spindle motor is

stopping.

Since it is necessary that motor power is off for spindle changing, please

set off the spindle rotation command (SFRA/SRVA) and the spindle

orientatation command (ORCMA) at switching spindle motors.

[Function] The selection status signal of the electromagnetic contactor for switching

the spindle motor power-lines is input.

0 : The main spindle is selected.

1 : The sub spindle is selected.

[Usage] Usually, the state of the auxiliary contact (contact A) of the magnetic

contactor for the sub spindle motor is entered directly.

[Function] When bit 2 of parameter No. 4014 (FS16) is set to 0, this signal is used

as the power line state check signal. So, the state of selection by the

magnetic contactor for spindle motor power line switching is entered.

0: The main spindle motor is selected.

1: The sub spindle motor is selected.

[Usage] In the case of changing from the main spindle to the sub spindle, this

signal is set from ”1” to ”0” after confirming that the electromagnetic

contactor on the main spindle side is off and that the electromagnetic

contactor on the sub spindle side is on.

In the case of changing from the sub spindle to the main spindle, this

signal is set from ”0” to ”1” after confirming that the electromagnetic

contactor on the sub spindle side is off and that the electromagnetic

contactor on the main spindle side is on.
