Alpha Series AC Servo Amplifier Descriptions Page 509

Descriptions

Page of 699

/ 699

B–65162E/03

11. OPTION RELATED TO SPINDLE

489

(d) Signal for integral speed control (INTGA)

[Function] Enables or disables integral speed control.

[Operation] When this signal is set to 1, integral speed control is disabled. (Same

effect as when the integral gain of the velocity loop is set to 0.) When the

signal is set to 0, integral speed control is enabled.

When the two spindles are mechanically connected with each other, this

signal is set to 1 for both spindles so that integral speed control is

disabled.

D When a cylindrical workpiece is held with the two spindles after they

are synchronized in speed

D When a workpiece with a unique shape is held with the two spindles

after they are synchronized in phase

(2) DO Signals (CNC to PMC)

(a) Signal address

#7 #6 #5 #4 #3 #2 #1 #0

F178 F044

FS0–T FS0–TT FS15 FS16 FS16–TT

Head2 Head2

F111

1st : F281 F1481 F229 F045 F1045

2nd : F285 F245 F049

SYCAL FSPPH FSPSY

MSPPHS MSPSYC

SPSYAL

SARA

RCFNA

(b) Signal indicating that synchronization control of spindle speed is completed (FSPSY)

[Function] Reports that synchronization control of spindle speed is completed.

[Output conditions] This signal is set to 1 when the following conditions are satisfied:

D In spindle synchronization control mode, the two spindles reach the

speed specified by the signal for specifying the spindle speed in

synchronization, and the difference between the speeds of the two

spindles is not more than the value specified in parameter 4033(FS16).

This signal is set to 0 when any of the following conditions is satisfied:

D In spindle synchronization control mode, the two spindles have not yet

reached the speed specified by the signal for specifying spindle speed

in synchronization.

D In spindle synchronization control mode, the difference between the

speeds of the two spindle is larger than the value specified in parameter

4033 (FS16).

D The spindles are not in spindle synchronization control mode.

NOTE

The signal changes from 1 to 0 when the difference in

spindle speed exceeds the value specified in parameter

4033(FS16) due to changes in the cutting load, etc.
