Alpha Series AC Servo Amplifier Descriptions Page 39

Descriptions

Page of 699

/ 699

B–65162E/03

2. CONFIGURATION AND ORDERING INFORMATION

Applicable detectors :

1. Spindle switching control

(switching the speed only, or switching both the speed and position)

2. Differential speed control (input circuit for position coder signals)

Category Name Ordering number

External dimensions

(H x W x D mm)

Remarks

SPM–11 A06B–6078–H411#H500

SPM–15 A06B–6078–H415#H500

Standard

SPM–22 A06B–6078–H422#H500

380150307

Standard

SPM–26 A06B–6078–H426#H500

SPM–30 A06B–6078–H430#H500

SPM–45 A06B–6088–H445#H500 380300307 (Note)

(d) Type 4 (high–resolution internal circuit incorporation specification)

Function used

1. α spindle sensor Cs contour control

Category Name Ordering number

External dimensions

(H x W x D mm)

Remarks

SPM–2.2 A06B–6078–H102#H500 38060307

SPM–5.5 A06B–6078–H106#H500

38090307

SPM–11 A06B–6078–H111#H500

38090307

(Note)

Standard

SPM–15 A06B–6088–H115#H500

Standard

SPM–22 A06B–6088–H122#H500

380150307

SPM–26 A06B–6088–H126#H500

380150307

SPM–30 A06B–6088–H130#H500

SPM–45 A06B–6088–H145#H500 380300307 (Note)

NOTE

SPM–11 (except type 3) and SPM–45 require forced air cooling from the outside. See (7) in

Section 2.2.3 and Chapter 7.
