2. CONFIGURATION AND ORDERING INFORMATION

B–65162E/03

NOTE

The NF3000C–TX series manufactured by SOSHIN ELECTRIC CO., LTD. and the FN258

series manufactured by SCHAFFNER have a large line–to–ground capacitor capacitance,

allowing a very high leakage current. Therefore, they can be used only for neutral grounding

type power supplies.

(13) Detectors

α position coder

Category Name Ordering number Remarks

tional

α position coder A860–0309–T302 j68, 10,000min

–1

O tional

Connector kit A06B–6088–K211 Straight type

High–resolution position coder

Category Name Ordering number Remarks

Optional High–resolution position coder A860–0319–T002 j68, 8,000min

–1

BZ sensor

Category Name Ordering number Remarks

BZ sensor 128 A860–0392–T012 128 teeth / 20,000min

–1

BZ sensor 256 A860–0392–T011 256 teeth / 15,000min

–1

BZ sensor 256S A860–0392–T014 256 teeth / 15,000min

–1

Optional

BZ sensor 384 A860–0392–T018 384 teeth / 15,000min

–1

BZ sensor 512 A860–0392–T013 512 teeth / 10,000min

–1

BZ sensor 128H A860–0392–T082 128 teeth / 50,000min

–1

BZ sensor 256H A860–0392–T081 256 teeth / 30,000min

–1

High–resolution magnetic pulse coder

Category Name Ordering number Remarks

A860–0382–T121 Outside diameter of drum: φ 65

tional

High–resolution magnetic

A860–0382–T122 Outside diameter of drum: φ 97.5

O tional

pulse coder

A860–0382–T123 Outside diameter of drum: φ 130

A860–0382–T124 Outside diameter of drum: φ 195
