9. CONNECTION
B–65162E/03
288
(21) Combined use of the high–resolution magnetic pulse coder incorporated into the motor and the
high–resolution position coder
SPM
TYPE 2
JY2
Spindle
Spindle motor
JY4
K18
K31
High–resolution magnetic pulse coder
Preamplifier
High–resolution position coder
Cable specification : Five 0.18mm
2
twisted pairs
Six 0.5mm
2
wires
Common shielded cable
Detailed description of the connection of cable K31
F
F
SPM JY4
(3)
(4)
(17)
(19)
(N), (T)
(9), (18), (20)
(12), (14), (16)
(10)
(M)
(L)
(P)
(C)
(F)
(G)
(A)
(D)
(B)
(E)
(J), (K)
PAE
*PAE
PBE
PSE
*PSE
+5V
0V
SS
*PBE
SS
Required connector (HIROSE)
Connector FI40B–20S
Housing FI–20–CV5
Cable +5V, 0V...three 0.5 mm
2
wires each
PAE, *PAE, PBE, *PBE, PSE, *PSE, AP, XAP, BP, XBP...0.18 mm
2
twisted pair
Recommended cable: A66L–0001–0368
See Appendix C for details.
Required connector Canon connector
(HIROSE ELECTRIC)
MS3106A20–29SW
FI40B–20S–CV5
(5)
(6)
(7)
(8)
(1)
(2)
(H)
High–resolution
position coder
AP
XAP
BP
XBP
PAE
*PAE
PBE
PSE
*PSE
+5V
0V
*PBE
AP
XAP
BP
XBP
