11. OPTION RELATED TO SPINDLE

B–65162E/03

482

Parameter No.

Description

FS0

Description

FS16FS15

3018#4 4018#4

Use of the α spindle sensor Cs contour control function. (To be set to

3719 4355 Amplitude ratio compensation (motor side)

3720 4356 Phase difference compensation (motor side)

3721 4357 Amplitude ratio compensation (spindle side)

3722 4358 Phase difference compensation (spindle side)

Setting related to the high–resolution magnetic pulse coder and high–resolution position coder

6501#5 3001#5 4001#5 Whether a high–resolution magnetic pulse coder is used (Set to 1.)

6501#6 3001#6 4001#6

Setting for using the position signal from a high–resolution magnetic

pulse coder for speed detection

6501#7 3001#7 4001#7 Mounting orientation for the high–resolution magnetic pulse coder

6504#0 3004#0 4004#0 Whether a high–resolution position coder is used

6500#0 3000#0 4000#0 Rotational direction of the spindle and motor

6503

#7,6,4

3003

#7,6,4

4003

#7,6,4

Position detector type setting

6502

#2, 1, 0

3002

#2, 1, 0

4002

#2, 1, 0

Setting for Cs contouring control resolution (Normally, set 0, 0, 0.)

Setting of a maximum spindle speed under Cs contour control

6521 3021 4021 Maximum spindle speed for Cs contouring control

Setting of a gear ratio between the spindle and motor

6556 to 6559

3056 to

3059

4056 to

4059

Gear ratio between spindle and motor

(selected by DI signals CTH1A and CTH2A)

Position gain setting

6569 to 6572

3069 to

3072

4069 to

4072

Position gain for the axis for which Cs contouring control is performed

(selected by DI signals CTH1A and CTH2A)

5609

#1, 0

Whether position gain is automatically set for axes for which Cs contour-

ing control is not performed

6780 to 6799

5609

#0, 1

3900 to

3944

Position gain for axes for which Cs contouring control is not performed

(selected by DI signals CTH1A and CTH2A)

Setting related to reference position return

6574 3074 4074 Zero point return speed in Cs contouring control

6592 3092 4092

Position gain change rate for zero position return in Cs contouring con-

trol

6500#3 3000#3 4000#3

Direction of zero point return at the first Cs contouring control after power

0065#1 1005#0 3700#1

Whether the zero point return function is used for the first G00 command

after switching to Cs contouring control mode
