3. HOW TO SELECT THE POWER SUPPLY MODULE

B–65162E/03

Table 4.1.1 (a) lists the maximum output capacities of the power supply

modules. Table 3.7.1 lists the accelerating maximum outputs of the servo

motors. Table 3.7.2 lists the accelerating maximum outputs of the spindle

motors.

Multiple servo amplifier modules and spindle amplifier modules can be

connected to a single power supply module, provided the above output

capacity conditions are satisfied.

The table below lists the maximum number of modules which can be

connected.

Maximum number of modules that can be connected

SVM

SVM1

SVM2

SVM3

SPM

SPMC

NOTE

1 When different types of servo amplifier modules are

connected, the following condition must be satisfied:

6 y Number of SVM1s×1+

Number of SVM2s×1.5+Number of SVM3s×2

The maximum number of servo amplifier modules that

can be connected is the same when a spindle amplifier

module is not used.

2 When SPM–30 is used, PSM–26 and power supply

modules with a capacity less than or equal to the

capacity of PSM–26 cannot be used.

When using SPM–45, use PSM–45.

When a machine, such as a press, with which a machining cycle is

performed frequently is used, select a PSM so that the total maximum

output of those axes that are accelerated/decelerated simultaneously does

not exceed the value 1.5 times greater than the rated continuous output.

Therefore, the PSM is selected as follows:

Motor PSM+SVM

α300/1200 PSM–37+SVM1–240 2

α400/1200 (PSM–30+SVM1–240) 2

3.3.3

Number of Connected

Servo Amplifier

Modules and Spindle

Amplifier Modules

3.3.4

Selecting a Power

Supply Module When

the Machining Cycle

Frequency is High

Examples
