B–65162E/03

11. OPTION RELATED TO SPINDLE

415

Unlike conventional mechanical spindle orientation using a stopper, etc.,

the spindle orientation stops the spindle at a fixed position by directly

feeding back position signals from the position coder directly connected

to the machine spindle.

This orientation is accomplished simply by connecting the position coder

to the spindle without any need of mechanical orientation mechanism

(stopper, pin, etc.) for spindle orientation.

Since the spindle motor connected to the spindle is utilized and the

orientation can be performed directly from high-speed rotation,

irrespective of gear shift, the orientation time is largely reduced.

This sequence consists of the spindle orientation command, its

completion signal, spindle clutch/gear only without any need of other

signals. Neither orientation speed command sequence nor torque limit

command sequence is needed.

Electrical system assures improved reliability without any damage to the

mechanical section against an external impact.

The spindle orientation accuracy and rigidity are enough to execute

automatic tool exchange (ATC).

Workpieces can be positioned to arrange their loading and unloading

directions in lathe.

Since the spindle orientation can be done in the same direction as the

rotating direction of the spindle when boring ends, workpieces will not

be damaged by tool blades.

Since these tool blades can be mounted or dismounted in a fixed direction

with reference to the workpieces, programming is easy.

11.1

SPINDLE

ORIENTATION

11.1.1

Position Coder Methed

Spindle Orientation (αC

Series Spindle)

11.1.1.1

General

11.1.1.2

Features

Mechanical parts are not

required.

Reduction of orientation

time

Simplified power

magnetic sequence

control

High reliability

High accuracy and

rigidity

Positioning of workpiece

Reduction of the number

of processes in boring
