B–65162E/03

11. OPTION RELATED TO SPINDLE

483

Parameter No.

Description

FS0

Description

FS16FS15

Grid shift setting

6635 3135 4135 Grid shift for Cs contouring control

Rotation direction setting

6500#1 3000#1 4000#1

Rotational direction of the spindle for + motion commands in Cs contour-

ing control

6502#4 3002#4 4002#4 Rotational direction signal function for Cs contouring control

Setting of a velocity loop gain and motor voltage

6546

6547

3046

3047

4046

4047

Velocity loop proportional gain for Cs contouring control

(selected by DI signal CTH1A)

6554

6555

3054

3055

4054

4055

Velocity loop integral gain for Cs contouring control

(selected by DI signal CTH1A)

6594 3094 4094

Compensation constant for external disturbance torque (acceleration

feedback gain)

6586 3086 4086 Motor voltage for Cs contouring control (Normally, set to 100.)

6516#4 3016#4 4016#4

Setting for control characteristics for Cs contouring control (Normally,

set 0.)

6519#0 3019#0 4019#0 Whether dead zone compensation is performed in Cs contouring control

6597 3097 4097 Spindle speed feedback gain

Others

6599 3099 4099 Delay time for exciting the motor
