11. OPTION RELATED TO SPINDLE

B–65162E/03

442

(1) Input Signals (PMC to CNC)

(a) Signal address

SHA07

SHA06

SHA05

SHA04

SHA03

SHA02

SHA01

SHA00

: G110 G231 G078

FS0 FS15 FS16

SHA11 SHA10 SHA09 SHA08

: G111 G230 G079

MRDYA ORCMA SFRA SRVA CTH1A CTH2A TLMHA TLMLA

: G229 G227 G070

RCHHGA MFNHGA INCMDA

OVRA

DEFMDA

NRROA ROTAA INDXA

: G231 G229 G072

First spindle control input signal

SHB07

SHB06

SHB05

SHB04

SHB03

SHB02

SHB01

SHB00

: G112 G239 G080

FS0 FS15 FS16

SHB11 SHB10 SHB09 SHB08

: G113 G238 G081

MRDYB ORCMB SFRB SRVB CTH1B CTH2B TLMHB TLMLB

: G223 G235 G074

RCHHGB MFNHGB INCMDB

OVRB

DEFMDB

NRROB ROTAB INDXB

: G235 G237 G076

Second spindle control input signals

(b) Orientation command signal (ORCMA)

A spindle orientation function of external incremental command setting

type is enabled during spindle orientation.

1: Performs orientation.

These signals are used to select a spindle control parameter (position gain,

gear ratio, velocity loop gain) that matches a selected clutch/gear. Names

such as High Gear are assigned only for convenience.

CTH1A CTH2A Gear/clutch state

High Gear (High)

Medium High Gear (High)

Medium Low Gear (Low)

Low Gear (Low)

(d) Incremental command data selection signal (INCMDA)

This signal is used to determine whether externally set data

(SHA00–SHA11) is used as stop position data or incremental command

data.

0: Uses SHA00–SHA11 as stop position data.

1: Uses SHA00–SHA11 as incremental command data.

(e) Shortcut rotation command (NRROA)

When stop position data is selected (INCMDA = 0) for stop position

modification, this signal rotates the spindle in the shortcut direction to the

target position. This signal is invalid when INCMDA = 1.

0:Rotates the spindle in the direction based on the parameter setting

(bits 2 and 3 of parameter No. 4003 (FS16) and ROTAA state.
