FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 122

Connection And Maintenance Manual
B-61813E/03 CONNECTIONS 9. TEMPERATURE INPUT MODULE
−113−
(2) 4-channel automatic measurement mode
(a) Flowchart
Specify the module type (DO17).
0 : Thermocouple module
1 : Thermoresistance module
Specify the sensor type (DO18).
0 : Pt/K
1 : JPt/J
Set the number of channels bit (DO24) to
"1".
Set NC READY (DO16) to "1".
When CH2 data READY (DI30 of input signal) becomes
"1", input signals DI16 to DI28 represent CH2 data.
START
N
ow ready to
measure.
When CH1 data READY (DI14 of input signal) becomes
"1", input signals DI00 to DI12 represent CH1 data.
Set the 4-channel mode specification bit (DO25)
to "0".
Specify the channel switching period (DO00 to
DO15).
When CH3 data READY (DI15 of input signal) becomes
"1", input signals DI00 to DI12 represent CH3 data.
When CH4 data READY (DI31 of input signal) becomes
"1", input signals DI16 to DI28 represent CH4 data.
*Check that NC READY
(DO16) and DO19 are "0".
