FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 75

Connection And Maintenance Manual
7. ANALOG OUTPUT MODULE CONNECTIONS B-61813E/03
−66−
7.1.2 Correspondence between Output Signals and Addresses in a
Module
In the analog output module ADA02A, a 12-bit digital value is written
into each of the following addresses to output the desired
voltage/current to its corresponding analog output.
(1) For PMC-N/Q (PMC for Series 15/F-D Mate)
Address
in module 7 6543210
0 ----D11-0D10-0D09-0D08-0
Channel 0
1 D07-0 D06-0 D05-0 D04-0 D03-0 D02-0 D01-0 D00-0
2 ----D11-1D10-1D09-1D08-1
Channel 1
3 D07-1 D06-1 D05-1 D04-1 D03-1 D02-1 D01-1 D00-1
(2) For PMC-M/R (PMC for Series 0/Series 16)
Address
in module 7 6543210
0 D07-0 D06-0 D05-0 D04-0 D03-0 D02-0 D01-0 D00-0
Channel 0
1 ----D11-0D10-0D09-0D08-0
2 D07-1 D06-1 D05-1 D04-1 D03-1 D02-1 D01-1 D00-1
Channel 1
3 ----D11-1D10-1D09-1D08-1
D00-n corresponds to the 2
0
weight, while D11-n corresponds to the 2
11
weight.
However, D11-n corresponds to the code bit 2's complement
representation.
NOTE
When setting an I/O module address, this module
initial adress must be assigned to an even address.
To write a value that is to be converted from digital to
analog into a PMC program, be sure to write it in
words (16 bits).
