FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 176

Connection And Maintenance Manual
We change following item as 1.4 in part II. MAINTENANCE.
1.4 LIST OF UNITS
Name I/O Unit-MODEL A not for UL/C-UL certification I/O Unit-MODEL A for UL/C-UL certification
Order no. Unit drawing no. P.C.B. drawing no. Order no. Unit drawing no. P.C.B. drawing no.
Base unit 10 slots Horizontal type ABU10A A03B-0807-J001 A03B-0807-C001 A20B-9001-0040 A03B-0819-J001 A03B-0819-C001 A20B-9001-0040
Vertical type ABU10B A03B-0807-J004 A03B-0807-C004 A20B-2003-0100
or A20B-2000-0550
A03B-0819-J004 A03B-0819-C004 A20B-2000-0550
5 slots Horizontal type ABU05A A03B-0807-J002 A03B-0807-C002 A20B-9001-0020 A03B-0819-J002 A03B-0819-C002 A20B-9001-0020
Vertical type ABU05B A03B-0807-J003 A03B-0807-C003 A20B-2000-0510 A03B-0819-J003 A03B-0819-C003 A20B-2000-0510
Interface module AIF01A A03B-0807-J011 A03B-0807-C011 A20B-8000-0410 A03B-0819-J011 A03B-0819-C011 A20B-8000-0410
AIF01B A03B-0807-J012 A03B-0807-C012 A20B-8000-0420 A03B-0819-J012 A03B-0819-C012 A20B-8000-0420
AIF02C A03B-0807-J013 A03B-0807-C013 A20B-8000-0710 A03B-0819-J013 A03B-0819-C013 A20B-8000-0710
DC input module Non- 32 points, 20ms AID32A1 A03B-0807-J101 A03B-0807-C101 A20B-9000-0970 A03B-0819-J101 A03B-0819-C101 A20B-9000-0970
insulated 32 points, 2ms AID32B1 A03B-0807-J102 A03B-0807-C102 A20B-9000-0971 A03B-0819-J102 A03B-0819-C102 A20B-9000-0971
32 points, 20/2ms AID32H1 A03B-0807-J111 A03B-0807-C111 A20B-9000-0972 A03B-0819-J111 A03B-0819-C111 A20B-9000-0972
insulated 16 points, NEG,
20ms
AID16C A03B-0807-J103 A03B-0807-C103 A20B-9000-0931 A03B-0819-J103 A03B-0819-C103 A20B-9000-0931
16 points, NEG,
2ms
AID16K A03B-0807-J113 A03B-0807-C113 A20B-9000-0932 A03B-0819-J113 A03B-0819-C113 A20B-9000-0932
16 points, POS,
20ms
AID16D A03B-0807-J104 A03B-0807-C104 A20B-9000-0901 A03B-0819-J104 A03B-0819-C104 A20B-9000-0901
16 points, POS,
2ms
AID16Ｌ
A03B-0807-J114 A03B-0807-C114 A20B-9000-0902 A03B-0819-J114 A03B-0819-C114 A20B-9000-0902
32 points, 20ms,
Honda
AID32E1 A03B-0807-J105 A03B-0807-C105 A20B-8002-0150
or A20B-9001-0010
A03B-0819-J105 A03B-0819-C105 A20B-8002-0150
32 points, 20ms,
Hirose
AID32E2 A03B-0807-J110 A03B-0807-C110 A20B-8002-0160
or A20B-9001-0280
A03B-0819-J110 A03B-0819-C110 A20B-8002-0160
32 points, 2ms,
Honda
AID32F1 A03B-0807-J106 A03B-0807-C106 A20B-8002-0151
or A20B-9001-0011
A03B-0819-J106 A03B-0819-C106 A20B-8002-0151
32 points, 2ms,
Hirose
AID32F2 A03B-0807-J109 A03B-0807-C109 A20B-8002-0161
or A20B-9001-0281
A03B-0819-J109 A03B-0819-C109 A20B-8002-0161
AC input module AIA16G A03B-0807-J107 A03B-0807-C107 A20B-8000-0341 A03B-0819-J107 A03B-0819-C107 A20B-8000-0341
DC output module Non-
insulated
32 points, NEG,
0.3A
AOD32A1 A03B-0807-J162 A03B-0807-C162 A20B-9001-0110 A03B-0819-J162 A03B-0819-C162 A20B-9001-0110
insulated 8 points, NEG, 2A AOD08C A03B-0807-J151 A03B-0807-C151 A20B-9000-0951
or A20B-9001-0210
A03B-0819-J151 A03B-0819-C151 A20B-9001-0210
8 points, POS, 2A AOD08D A03B-0807-J152 A03B-0807-C152 A20B-9000-0911
or A20B-9001-0220
A03B-0819-J152 A03B-0819-C152 A20B-9001-0220
16 points, NEG,
0.5A
AOD16C A03B-0807-J153 A03B-0807-C153 A20B-9000-0941 A03B-0819-J153 A03B-0819-C153 A20B-9000-0941
16 points, POS,
0.5A
AOD16D A03B-0807-J154 A03B-0807-C154 A20B-9000-0921 A03B-0819-J154 A03B-0819-C154 A20B-9000-0921
16 points, POS,
0.3A,
Circuit protection
AOD16DP A03B-0807-J182 A03B-0807-C182 A20B-8002-0070 A03B-0819-J182 A03B-0819-C182 A20B-8002-0070
32 points, NEG,
0.3A, Honda
AOD32C1 A03B-0807-J155 A03B-0807-C155 A20B-9001-0070 A03B-0819-J155 A03B-0819-C155 A20B-9001-0070
32 points, NEG,
0.3A, Hirose
AOD32C2 A03B-0807-J172 A03B-0807-C172 A20B-9001-0530 A03B-0819-J172 A03B-0819-C172 A20B-9001-0530
32 points, POS,
0.3A, Honda
AOD32D1 A03B-0807-J156 A03B-0807-C156 A20B-8000-0440 A03B-0819-J156 A03B-0819-C156 A20B-8000-0440
32 points, POS,
0.3A, Hirose
AOD32D2 A03B-0807-J167 A03B-0807-C167 A20B-8000-0510 A03B-0819-J167 A03B-0819-C167 A20B-8000-0510
AC output module 5 points, 2A AOA05E A03B-0807-J157 A03B-0807-C157 A20B-8000-0470
or A20B-8000-0251
A03B-0819-J157 A03B-0819-C157 A20B-8000-0470
8 points, 1A AOA08E A03B-0807-J158 A03B-0807-C158 A20B-8000-0480
or A20B-8000-0381
A03B-0819-J158 A03B-0819-C158 A20B-8000-0480
12 points, 0.5A AOA12F A03B-0807-J159 A03B-0807-C159 A20B-8000-0321 A03B-0819-J159 A03B-0819-C159 A20B-8000-0321
Relay output module 8 points, 4A AOR08G A03B-0807-J160 A03B-0807-C160 A20B-9001-0200
or A20B-9000-0961
A03B-0819-J160 A03B-0819-C160 A20B-9001-0200
16 points, 2A AOR16G A03B-0807-J161 A03B-0807-C161 A20B-8000-0101 A03B-0819-J161 A03B-0819-C161 A20B-8000-0101
16 points, 2A,
Hirose
AOR16H2 A03B-0807-J165 A03B-0807-C165 A20B-8000-0500 A03B-0819-J165 A03B-0819-C165 A20B-8000-0500
Analog input module AAD04A A03B-0807-J051 A03B-0807-C051 A20B-8000-0450 A03B-0819-J051 A03B-0819-C051 A20B-8000-0450
Analog output module 12bit ADA02A A03B-0807-J052 A03B-0807-C052 A20B-8000-0460 A03B-0819-J052 A03B-0819-C052 A20B-8000-0460
14bit ADA02B A03B-0807-J060 A03B-0807-C060 A20B-8001-0980 A03B-0819-J060 A03B-0819-C060 A20B-8001-0980
High speed counter module ACT01A A03B-0807-J053 A03B-0807-C053 A20B-8000-0540 A03B-0819-J053 A03B-0819-C053 A20B-8000-0540
Temperature input module Pt/JPt ATI04A A03B-0807-J056 A03B-0807-C056 A74L-0001-0083#PT A03B-0819-J056 A03B-0819-C056 A74L-0001-0083#PT
J/K ATI04B A03B-0807-J057 A03B-0807-C057 A74L-0001-0083#JK A03B-0819-J057 A03B-0819-C057 A74L-0001-0083#JK
Terminal unit Pt/JPt ATB01A A03B-0807-J350 A03B-0807-C350 A20B-1005-0920 A03B-0819-J350 A03B-0819-C350 A20B-1005-0920
J/K ATB01B A03B-0807-J351 A03B-0807-C351 A20B-1005-0930 A03B-0819-J351 A03B-0819-C351 A20B-1005-0930
Name Order No. PCB drawing No.
Optical adapter A13B-0154-B001 A20B-1004-0240
Dummy unit A13B-0167-B001 A20B-8000-0940
EDIT
.
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
3/3
DESCRIPTIONDESIG.DATE
FANUC I/O Unit-MODEL A
Additional matter of CONNECTION
MAINTENANCE MANUAL
B-61813E/03-2
