FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 96

Connection And Maintenance Manual
B-61813E/03 CONNECTIONS 8. HIGH SPEED COUNTER MODULE
−87−
8.4.2 Connector signal list
JA9
10 20 +5V
9 +5V 19
8 PSEL 18 +5V
7LGND 17
6*MKS 16LGND
5MKS 18
4 *PBS 14 LGND
3 PBS 13
2 *PAS 12 LGND
1 PAS 11
PAS : Phase A pulse input signal (Negative pulse input
signal)(positive)
*PAS : Phase A pulse input signal (Negative pulse input
signal)(negative)
PBS : Phase B pulse input signal (Positive pulse input
signal)(positive)
*PBS : Phase B pulse input signal (Positive pulse input
signal)(negative)
MKS : Marker signal (positive)
*MKS : Marker signal (negative)
PSEL : Pulse select signal
+5V : 5V (output from this module)
LGND : 0V
C49
AB
01 ME
02 CSP
03 COM1
04
05
06 OUT0 OUT4
07 OUT1 OUT5
08 OUT2 OUT6
09 OUT3 OUT7
10 COM2 COM3
ME : Marker enable signal input
CSP : Counter stop signal input
OUT0 : Comparison result output
OUT1 : Comparison result output
OUT2 : Comparison result output
OUT3 : Comparison result output
OUT4 : Comparison result output
OUT5 : Comparison result output
OUT6 : Comparison result output
OUT7 : Comparison result output
COM1 : Common signal for ME and CSP
COM2 : Common signal for comparison result
output 0 to comparison result output 3
COM3 : Common signal for comparison result
output 4 to comparison result output 7
