FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 148

Connection And Maintenance Manual
B-61813E/03 MAINTENANCE 1. OVERVIEW
−139−
Name Arrangement
drawing No.
Unit drawing
No.
PCB drawing
No.
16 points.
NEG
AOD16C A03B-0807-J153 A03B-0807-C153 A20B-9000-0941
16 points.
POS
AOD16D A03B-0807-J154 A03B-0807-C154 A20B-9000-0921
32 points.
NEG
AOD32C1 A03B-0807-J155 A03B-0807-C155 A20B-9001-0070
32 points.
NEG
AOD32C2 A03B-0807-J172 A03B-0807-C172 A20B-9001-0530
32 points.
POS
AOD32D1 A03B-0807-J156 A03B-0807-C156 A20B-8000-0440
DC
output
module
Insulations
32 points.
POS
AOD32D2 A03B-0807-J167 A03B-0807-C167 A20B-8000-0510
5 points.
2A
AOA05E A03B-0807-J157 A03B-0807-C157 A20B-8000-0470
or -8000-0251
8 points.
1A
AOA08E A03B-0807-J158 A03B-0807-C158 A20B-8000-0480
or -8000-0381
AC output module
12 points.
0.5A
AOA12F A03B-0807-J159 A03B-0807-C159 A20B-8000-0321
8 points.
4A
AOR08G A03B-0807-J160 A03B-0807-C160 A20B-9001-0200
or -9000-0961
16 points.
2A
AOR16G A03B-0807-J161 A03B-0807-C161 A20B-8000-0101
Relay output module
16 points.
2A
AOR16H2 A03B-0807-J165 A03B-0807-C165 A20B-8000-0500
Analog input module AAD04A A03B-0807-J051 A03B-0807-C051 A20B-8000-0450
Analog output module (12-bit) ADA02A A03B-0807-J052 A03B-0807-C052 A20B-8000-0460
Analog output module (14-bit) ADA02B A03B-0807-J060 A03B-0807-C060 A20B-8001-0980
High speed counter module ACT01A A03B-0807-J053 A03B-0807-C053 A20B-8000-0540
Pt/Pt AT104A A03B-0807-J056 A03B-0807-C056 A74L-0001-0083#PtTempereture input module
J/K AT104B A03B-0807-J057 A03B-0807-C057 A74L-0001-0083#JK
Pt/Pt ATB01A A03B-0807-J350 A03B-0807-C350 A20B-1005-0920Relay terminal unit
J/K ATB01B A03B-0807-J351 A03B-0807-C351 A20B-1005-0930
Optical adapter A13B-0154-B0001 - A20B-1004-0240
Dummy unit A13B-0167-B0001 - A20B-8000-0940
