FANUC I/O Unit-MODEL A Connection And Maintenance Manual Page 147

Connection And Maintenance Manual
1. OVERVIEW MAINTENANCE B-61813E/03
−138−
1.4 LIST OF UNITS
Name Arrangement
drawing No.
Unit drawing
No.
PCB drawing
No.
Horizontal type ABU10A A03B-0807-J001 A03B-0807-C001 A20B-9001-0040Base unit.
10 slots
Vertical type ABU10B A03B-0807-J004 A03B-0807-C004 A20B-2000-0550
or -2003-0100
Horizontal type ABU05A A03B-0807-J002 A03B-0807-C002 A20B-2000-0020Base unit
5 slots
Vertical type ABU05B A03B-0807-J003 A03B-0807-C003 A20B-9001-0510
Interface module AIF01A A03B-0807-J011 A03B-0807-C011 A20B-8000-0410
Interface module AIF01B A03B-0807-J012 A03B-0807-C012 A20B-8000-0420
Interface module AIF02C A03B-0807-J013 A03B-0807-C013 A20B-8000-0710
32 points.
20ms
AID32A1 A03B-0807-J101 A03B-0807-C101 A20B-9000-0970
32 points.
2ms
AID32B1 A03B-0807-J102 A03B-0807-C102 A20B-9000-0971
Non-
insulations
8 points.
2ms
24 points.
20ms
AID32H1 A03B-0807-J111 A03B-0807-C111 A20B-9000-0972
16 points.
NEG, 20ms
AID16C A03B-0807-J103 A03B-0807-C103 A20B-9000-0931
16 points.
POS, 20ms
AID16D A03B-0807-J104 A03B-0807-C104 A20B-9000-0901
16 points.
NEG, 2ms
AID16K A03B-0807-J113 A03B-0807-C113 A20B-9000-0932
16 points.
POS, 2ms
AID16L A03B-0807-J114 A03B-0807-C114 A20B-9000-0902
32 points.
20ms
AID32E1 A03B-0807-J105 A03B-0807-C105 A20B-9001-0010
32 points.
20ms
AID32E2 A03B-0807-J110 A03B-0807-C110 A20B-9001-0280
32 points.
2ms
AID32F1 A03B-0807-J106 A03B-0807-C106 A20B-9001-0011
DC
input
module
Insulations
32 points.
2ms
AID32F2 A03B-0807-J109 A03B-0807-C109 A20B-9001-0281
AC input module. 16 points AIA16G A03B-0807-J107 A03B-0807-C107 A20B-8000-0341
Non
insulations
32 points.
NEG
AOD32A1 A03B-0807-J162 A03B-0807-C162 A20B-9001-0110
8 points.
NEG
AOD08C A03B-0807-J151 A03B-0807-C151 A20B-9001-0210
or -9000-0951
DC
output
module
Insulations
8 points.
POS
AOD08D A03B-0807-J152 A03B-0807-C152 A20B-9001-0220
or -9000-0911
