FANUC SERIES 15-150 MODEL B Maintenance manual Page 218

Maintenance manual
B–62075E/04
3. INPUT AND OUTPUT OF DATA
198
(4)+INPUT: Adds an input value to the data at the cursor position
so that the sum is entered at the cursor position
(parameters other than bit parameters).
(5)INPUT: Enters an input value at the cursor position.
(6)READ: Enters parameters from the reader/punch interface.
(7)PUNCH: Outputs parameters to the reader/punch interface.
4 Ending parameter writing
After terminating parameter write operation, return bit 0 of setting data
No. 8000 to 0 by using the same procedure as described in Item 1
above. Then, press
RESET
to release the SW000 alarm.
5 Simple setting methods
(1)Bit–by–bit setting
The cursor can be resized to the one–bit size by pressing the cursor
keys
and , thus enabling bit–by–bit setting (only for bit
parameters).
(2)Successive data setting starting at the cursor position
Data items can be successively entered by inserting
EOB
HELP
between
adjacent data items.
Example 1:
1
2
3
4
EOB
HELP
5
6
7
8
EOB
HELP
9
9
9
9
INPUT
INSERT
0
0
0
0
0
1234
5678
9999
0
0
Example 2:
1
2
3
4
EOB
HELP
EOB
HELP
9
9
9
9
INPUT
INSERT
0
0
0
0
0
1234
0
9999
0
0
