FANUC SERIES 15-150 MODEL B Maintenance manual Page 239

Maintenance manual

Page of 420

/ 420

B–62075E/04

3. INPUT AND OUTPUT OF DATA

219

3) Press the [CHAPTER] soft key.

4) Press the [TEXT] soft key.

The program contents screen can also be displayed by pressing the

PROG

key several times.

5 Press the

operation menu key to display [READ] in the soft key

menu.

6 Press the [READ] soft key, then enter

Program Number

. Next,

press the [EXEC] soft key to register the program for macro variable

value input.

NOTE For Program Number, enter the number of the program to be

used.

7 Select memory (automatic operation) mode, then press the cycle start

button to start automatic operation.

The program runs, and the custom macro values are set.

8 Upon the completion of the operation, display the custom macro

variable screen.

9 By switching between pages with the page keys

and , check

that the custom macro variable values have been entered correctly.

10 Select edit mode.

11 Display the program contents screen.

12 Delete the program registered for custom macro variable value input.

Enter

Program Number

DELETE

to delete the program.

1 Select edit mode.

2 Set memory protection key KEY1 to ON (KEY1 = 1).

3 Prepare a program for tool offset data input on the I/O device side.

4 Display the program contents screen.

1) Press the

PROG

key.

2) Press the

function menu key.

3) Press the [CHAPTER] soft key.

4) Press the [TEXT] soft key.

The program contents screen can also be displayed by pressing the

PROG

key several times.

5 Press the

operation menu key to display [READ] in the soft key

menu.

6 Press the [READ] soft key, then enter

Program Number

. Next,

press the [EXEC] soft key to register the program for tool offset data

input.

* For Program Number, enter the number of the program to be used.

3.2.3.6

Tool offset data input
