B–62075E/04

3. INPUT AND OUTPUT OF DATA

216

NOTE

To change the baud rate, press the [PCPRM] soft key on the

menu as shown in the figure in step 1., and press the

[MODE] soft key. Then place the cursor at DATA

TRANSFER RATE (AUX) using the key. Press the soft

key to display the desired baud rate.

1. Connect the reader/punch inerface of the CNC to the input device

which contains PMC data. Then turn the CNC on.

2. Put the CNC in the MDI mode or emergency stop mode.

3. Press teh [SETTING] soft key to display the setting screen.

4. Enter 8000 and press the [INP–NO.] softkey. Prameter No. 8000 is

displayed.

5. If PWE, the lowest bit of paramter No. 8000, is set to 0, change it to

1. Then press the [INPUT] soft key. This sets the PWE bit to 1 and

puts the NC in the alarm mode.

6. Press the

PMC

CNC

soft key to display the PMC screen.

PCMDI PCLAD PDDGN PCPRM

7. Press the PCPRM soft key to display teh PC parameter screen. The

sofy keys are displayed as shouwn below.

TIMER

MODE

PCLAD

I/O

KEEPRL

CLRPRM

DATA POS

– ETC –

8. Press the I/O soft key . (For 9″ CRT, press the [–ETC–] key.)

INPUT OUTPUT

9. Press the INPUT sofy key. Then enter the name or number of the file

and press the [EXEC] key.

EXEC

10.The corresponding addresses are displayed to show that the data has

been correctly ihnput.

3.2.3.3

Inputting PMC data
