APPENDIX

B–62075E/04

B. BOOT SYSTEM

340

The table below lists the functions and corresponding memory card types

that can be used. Cards must be of TYPE 1 or 2 as defined in the Personal

Computer Memory Card International Association (PCMCIA) standard,

version 2.0 or later, or the Japan Electronic Industry Development

Association (JEIDA) standard, version 4.1 or later. The format conforms

to the DOS FAT file system.

The memory card has a maximum storage capacity of 32M bytes.

Flash memory card

SRAM card

Supported

(*1)(*2)

Not supported

File read f f f

Card format f f

File write f f

File list f f f

NOTE

1 The following flash memory cards are supported:

S Intel Series 2 flash memory card (or equivalent)

S Intel Series 2+ flash memory card (or equivalent)

Both types require the use of attribute memory. For other

flash memory cards, see the rightmost column “Not

supported” in the table shown above.

S The ATA flash memory card cannot be used.

S With the PMC–NA, the flash memory card is used only

for the boot system.

2 Some flash memory cards, written using the memory card

interface built into a personal computer, may use a format

other than that indicated above. Such memory cards

cannot be used.

B.1.4

Memory Cards for Use

with the Boot System
