FANUC SERIES 15-150 MODEL B Maintenance manual Page 301

Maintenance manual

Page of 420

/ 420

B–62075E/04

5. TROUBLESHOOTING

281

(1)Check whether position display is operating.

(2)Check CNC status display

(3)Check internal status using Diagnostic funciton

(1)Check mode selection status (JOG mode is not selected)

When status display shows JOG, it is normal.

When status display does not show JOG, mode select signal is not

selected correctly. Confirm the mode select signal using PMC’s

diagnostic function (PMCDGN).

G003

#6 #5 #4 #3 #2

#1 #0

(M/T series)

G097

#6 #5 #4 #3 #2

#1 #0

(TT series)

(2)Feed axis and direction select signal is not input Check the signal using

PMC’s diagnostic function (PMCDGN).

+J8G100

+J7

+J6

+J5

+J4

+J3

+J2

+J1

–J8G102 –J7 –J6 –J5 –J4 –J3 –J2 –J1

Example)

When +X button is pressed on the operator’s panel, signal+J1 turns

to 1.

* This signal is effected at its rise. If axis selection signal is input

before JOG mode is selected, axis movement does not occur. Turn

the signal to off, then on.

(3)Check the status according to CNC diagnostic function Nos. 1000 and

1001. Investigate any items for which 1 is displayed on the right.

No. 1001

a. INPOSITION CHECK

FEEDRATE OVERRIDE 0

b. JOG FEED OVERRIDE 0

c. INT./START LOCK ON

SPEED ARRIVAL ON

WAIT REVOLUTION

STOP POSITION CODER

FOREGROUND READING

5.4

JOG OPERATION

CANNOT BE DONE

Points

Causes and Remedies

1. Position display

(relative, absolute,

machine cooordinate)

does not change
