FANUC SERIES 15-150 MODEL B Maintenance manual Page 271

Maintenance manual
B–62075E/04
4. INTERFACE BETWEEN NC AND PMC
251
(2)Data table
DATA TABLE DATA #001
NO. ADDRESS DATA
0000 D0026 20
0001 D0027 30
0002 D0028 40
@@
@@
@@
0019 D0045 99
Data table group number
(1)Data table setting screen
PMC DATA TBL CONTROL #001
G.DATA
G.CONT NO.SRH
MONIT RUN
INIT
No. of screen
NO. ADDRESS PARAMETER TYPE NO.OF DATA
001 D0000 00000000 0 10
002 D0020 00000011 1 20
003
004
005
006
007
008
No. of
data table
groups
No. of
data table
GROUP TABLE COUNT = 2
Group no. of
data table
Data table
head ad-
dress
Data length
Table
parameter
a. Soft key [G.DATA] : Select data display screen of data table.
(Next screen)
b.
NO. OF GROUPS [G.CONT]: Set the no. of groups of data table.
c.
Group No.
[NO.SRH]:Move the cursor to a specified group.
d. Soft key [INIT]: Initializes the setting of data table.
No. of groups is 1, ADDRESS is D0000, PARAMETER is 0000000,
TYPE is 0, NO. OF DATA is 1860.
* This operation is done usually when a sequence program is prepared.
When PMC parameters are set, internal parameters are not affected.
D PMC–NB
Previous page
Next page
