APPENDIX

B–62075E/04

B. BOOT SYSTEM

338

When the following display appears, select the MDI unit to be used. To

use a lathe–system MDI unit, press the

INPUT

INSERT

key. To use a machining–

center MDI unit, press the

CAN

key. Once the MDI has been set,

SYSTEM MONITOR is selected.

SET MDI KEYBOARD TYPE

F15 T/TT –– PUSH INPUT KEY

F15 M –– PUSH CANCEL KEY

The boot system manages the files in flash memory by dividing them into

two large categories: system files and user files. These two file types

differ as described below:

Files of the CNC or servo control software provided by FANUC

User–created files of a PMC sequence program (ladder), P–CODE macro

program, or the like

Setting the 9″ small MDI

unit

B.1.3

System File and User

File

D System files

D User files
