FANUC SERIES 15-150 MODEL B Maintenance manual Page 243

Maintenance manual
B–62075E/04
3. INPUT AND OUTPUT OF DATA
223
6. Enter address and program number information.
Parameter
P
<
*
)
9 9 9 9
Tool file
T
*
)
9 9 9 9
Cutting condition file
F
%
*
)
9 9 9 9
Pre–tool list
R
*
)
9 9 9 9
PASCAL
¥
S
*
)
9 9 9 9
Conversational data
M
SP
*
)
9 9 9 9
All programs
O
?
*
)
9 9 9 9
7. Press [READ] to read the specified data.
(Notes on program input)
D Specifying the conversational parameter (No. 000/RDAL) enables
the entry of all programs simply by pressing [READ] without
entering O–9999.
D Enter
O
?
*
)
9 9 9 9
.
,
R
E
$
P
<
,
in this order, to replace the program with a previously registered
program having the same program number.
1. Set a data input/output parameter.
(See Item 1 of Section 3.2.4.2.)
2. For program output, set a desired punch code with the conversational
setting data (No. 058/EIA).
3. Set the I/O device to enable output.
4. Display the data input/output screen.
5. Enter address and program number information.
(See Item 6 of Section 3.2.4.2.)
6. Press [PUNCH] to punch the specified data.
3.2.4.3
Conversational data
output
