FANUC SERIES 15-150 MODEL B Maintenance manual Page 269

Maintenance manual
B–62075E/04
4. INTERFACE BETWEEN NC AND PMC
249
#1 DBGSTAT 0: In the C language debug function, the automatic break processing
does not start when the power is turned on.
1 : In the C language debug function, the automatic break processing
starts when the power is turned on.
#0 IGNKEY 0 : Function keys are enabled when a user program displays the user
screen.
1 : Function keys are disabled when a user program displays the user
screen.
* When this bit is set to 1 of the user screen, the screen cannot be switch
to the NC screen using function keys. A program which always sets
this bit to 0 or which changes the screen to the NC screen is required.
#7
K019
#6 #5 #4 #3 #2 #1 #0
These bits are status of not used for PMC management software are used
by system. Do not change the values.
Usually all the bits are 0.
A data table is displayed according to the parameters specified for the
control data.
DATA TABLE CONTROL DATA
NO. ADDRESS PARAMETER NO.OF DATA
000 D0000 3
001 D0002 00000000 20
001 D0010 00000010 20
001 D0018 00001000 50
DATA TABLE DATA #001
NO. ADDRESS DATA
0000 D0026 20
0001 D0027 30
0002 D0028 40
@@
@@
@@
0019 D0045 99
D DATA (data table) screen
Previous page
Next page
