FANUC SERIES 15-150 MODEL B Maintenance manual Page 231

Maintenance manual

Page of 420

/ 420

B–62075E/04

3. INPUT AND OUTPUT OF DATA

211

(1)Connect a PMC data output device to the reader/punch interface, then

turn on the power.

(2)Press the

PMC

CNC

key to display the PMC screen. When the soft keys in

the lower row shown below are displayed, operations (1) through (9)

are not required.

PMCLAD

STOP

PMCDGN

EDIT

PMCPRM

I/O SYSPRM

For the 9″ CRT

display

(3)Press the

PMC

CNC

key to display the CNC screen. Then, set the MDI

mode or emergency stop state.

(4)Press the [SETTING] soft key to select the setting screen.

(5)Key in 8000, then press the [INP–NO.] soft key. Data No. 8000 is

displayed.

(6)When the least significant bit (PWE) of data No. 8000 is 0, key in 1,

then press the [INPUT] soft key. Then, PWE = 1 is set, and the CNC

is placed in the alarm state.

(7)Press the

PMC

CNC

key to display the PMC screen.

(8)Press the [PCMCPRM] soft key then the [KEEPRL] soft key. A list

of keep relays is displayed. Position the cursor, using the

key,

to the K17 data then key in 10. Next, press the

INPUT

INSERT

key to set bit 1

of K17 to 1. (Memorize the K17 setting before making this

modification as it will be used again in step (11).)

PMCLAD

TIMER

PMCDGN

COUNTR

PMCPRM

KEEPRL DATA

Position the cursor to the K17 data with the

key.

“10”

INPUT

INSERT

(9)Press the key (leftmost soft key) several times to display the soft

key menu of (1).

(10) Press the [I/O] soft key to display the I/O screen.

(11) Key in the correct channel number from the keyboard, then press the

INPUT

INSERT

key.

Example: “1”

INPUT

INSERT

key

D PMC–NB
