B-63344EN/02 OPERATION 10.CONVERTING MACHINING PROGRAM INTO NC PROGRAM

- 91 -

10.2 ALARMS DURING CONVERSION OF THE MACHINING

PROGRAM INTO NC PROGRAM

While the machining program is being converted into the NC program,

the machining program is running for check drawing. A P/S alarm

may occur because of the contents of the machining program.

For the P/S alarms, see appendix II. which describes the alarms that

may occur when the machining program is running. Then correct the

machining program.

If the P/S alarm occurs during the conversion, the converted part of

the machining program has already been stored in the tape memory

area. To restart the conversion of the machining program, correct the

erroneous part, delete the converted part, and perform conversion

from the beginning.

The following alarms may occur while the conversion.

Alarm

No.

Description

Cause Insufficient tape memory area070

Action Take the following action depending on the condition:

1) If another NC program is already registered and

the remaining memory is insufficient for the

program being currently converted.

-> Save the registered NC program in the external

memory unit via the reader/puncher interface,

delete the program, and resume conversion.

2) If the entire reserved area is insufficient for the

program being currently converted.

-> The NC program area can be increased by setting

parameters. However, this causes the manual

guide program area to be reduced and all data

items to be cleared temporarily.

Cause The number of registered programs (it depends on an

optional setting) exceeded.

072

Action Save some of the registered NC programs into the

external memory unit via the reader/puncher interface,

delete the programs, and resume conversion from the

beginning.

Cause An attempt was made to specify the same program

number as that of a registered program.

073

Action Delete the registered NC program having the same

number and resume conversion from the beginning.
