Manual Guide 16i/18i/21i - TA Operators manual Page 314

Operators manual
C.DYNAMIC GRAPHIC DISPLAY FOR NC PROGRAMS APPENDIX B-63344EN/02
- 302 -
G10 P90050 ;
End of registration of the tool figure
Assign a graphic registration number (1 to 16) to each tool to be
used and input the above registration commands.
(3) Tool selection
Immediately before a tool is used in the NC program, select the tool
from multiple tool figures registered in advance as described above.
G10 P90060 Q(Gn) R(R) ;
Selects the tool figure having graphic registration number Gn (1
to 16) as a tool for drawing. R can be specified for mirroring the
drawing.
R= 0 : X-axis off and Z-axis off
1 : X-axis on and Z-axis off
2 : X-axis off and Z-axis on
3 : X-axis on and Z-axis on
NOTE
When the drawing mode is set to 1, the tool
selection command is also required. In this case,
specify a dummy number between 1 and 16 for Q.
(4) Screen initialization
Specify the following command to draw a blank after completion of
registration of the blank figure.
G10 P90099 ;
