Manual Guide 16i/18i/21i - TA Operators manual Page 187

Operators manual
B-63344EN/02 SUPPLEMENT 1.CALCULATING INPUT DATA
- 175 -
1.2 OPERATION
Use the following key operations for the arithmetic operations :
(1) Addition : 100.+200.[INPUT]
(2) Subtraction : 100.-200.[INPUT]
(3) Multiplication : 100.*20.[INPUT]
(4) Division : 100./10.[INPUT]
The displayed result of an operation is not directly entered in the
numeric data item. The operator must check the displayed result of an
operation, then press [INPUT] to enter the result in the input data
item.
Example)
210. - 65.3 + 1.25
Key input operation and displayed results of pressing the INPUT
key for the above operation
• Key operation
INPUT
INPUTINPUT
INPUTINPUT
INPUTINPUT
INPUT
52.1+
INPUT
INPUTINPUT
INPUT
2 3.56-.01
• Key-in buffer display
210.-65.3 START X
(INPUT key)
144.7 START X
• (Key operation for the second operation)
144.7+1.25 START X
• (INPUT key)
145.95 START X
• (INPUT key)
The operation result (149.95) is input to the START X data item.
