Manual Guide 16i/18i/21i - TA Operators manual Page 286

Operators manual
A.PARAMETERS APPENDIX B-63344EN/02
- 274 -
A.6 PARAMETER FOR BAR MACHINING
9795 CUTCHG
CUTCHG Rate of change in the depth of cut in bar machining. If the parameter
is set to 0, the depth of cut remains unchanged.
Valid data range : 0 to 200
Units : 1%
Example)
When the depth of cut is 5mm, CUTCHG is 70%, and CUTMIN
is 1.5mm, the depth of cuts are as follows.
First cut 5mm
2nd 3.5mm
3rd 2.45mm
4th 1.715mm
5th 1.5mm
6th 1.5mm
9796 CUTMIN
CUTMIN Minimum limit of depth of cut (radius) in bar machining.
Valid data range : 0 to 99,999,999
Units : 0.001mm
0.0001inch
9797 RELFX
RELFX Default value of X component (diameter) of a clearance from the
cutting surface in in-feed machining of Outer and Inner bar
machining.
Valid data range : 0 to 99,999,999
Units : 0.001mm
0.0001inch
9798 RELFZ
RELFZ Default value of Z component (radius) of a clearance from the cutting
surface in in-feed machining of Face bar machining.
Valid data range : 0 to 99,999,999
Units : 0.001mm
0.0001inch
