Manual Guide 16i/18i/21i - TA Operators manual Page 278

Operators manual

Page of 333

/ 333

A.PARAMETERS APPENDIX B-63344EN/02

- 266 -

#7 #6 #5 #4 #3 #2 #1 #0

9779 G32 CRC CRF

CRF 1 : When forward rotation is specified by the C-axis end face tool

rotation command, the M code for reverse rotation is output.

When reverse rotation is specified, the M code for forward

rotation is output. For C-axis tapping, the M code specified for

parameter No. 9861 (CRVMCD) is output immediately before

the tapping command.

0 : The above function is disabled.

CRC 1 : When forward rotation is specified by the C-axis side face tool

rotation command, the M code for reverse rotation is output.

When reverse rotation is specified, the M code for forward

rotation is output. For C-axis tapping, the M code specified for

parameter No. 9861 (CRVMCD) is output immediately before

the tapping command.

0 : The above function is disabled.

G32 1 : Tapping for turning is done by G32.

0 : Tapping for turning is done by G84.

Example)

G32=0 :

X0. M8 ;

Z6. ;

G99 G84 Z-30. R0. F0.5 P225 ;

G80 ;

G32=1 :

X0. M8 ;

Z6. ;

G32 Z-30. R0. F0.5 M5 ;

Z6. M4 ;

G99 ;

#7 #6 #5 #4 #3 #2 #1 #0

9845 SPE RSC ETC WOP UMC NEX NTL

NTL 1 : The tool data window is not displayed.

0 : The tool data window is displayed.

NEX 1 : Soft-key for executing playback [EXEC] is not displayed.

0 : The above soft-key is displayed.

UMC 1 : Each auxiliary function specified by calling a user program is

enabled on the MANUAL GUIDE initial screen, guidance and

single cutting screens, and cycle screen.

0 : Each auxiliary function specified by calling a user program is

enabled only on the MANUAL GUIDE initial screen and

guidance and single cutting screens.

WOP 1 : A user window can be displayed using an external key. Eight

types of windows can be displayed. A user window can be

displayed at a time; multiple user windows cannot be displayed

simultaneously.

0 : No user window can be displayed using any external key.
