3.USEFUL FUNCTIONS FOR MACHINING PROCESSES SUPPLEMENT B-63344EN/02

- 196 -

(4) Reverse rigid tapping by turning :

When the parameter No.9779#6(G32) is set to 0.

(M8/M9);

G50 S_ ;

G99G40T_ ;

G80;

(Movement to the cutting start point)

M(Reverse spindle rotation tapping pre-command P9293);

S_ M(Rigid tapping mode command P5210);

G99G84Z_ R0.F_ P_ ;

G80;

NOTE

When bit 4 (TTM) of parameter No. 9846 is set to 0

or when the bit is set to 0 and parameter No. 9293

is not set, reverse rotation may be specified as the

direction of rotation for tapping. In this case, P/S

alarm, "3008 A WRONG TOOL SELECTED," is

issued.

(5) C-axis forward tapping by milling, even spacing

M(Milling axis stop command P9876);

(M8/M9);

M(Milling forward tapping pre-command P9088); . . . (C)*

G97G98G40S_ T_ M(Forward milling axis rotation command P9877)

G80;

(Movement to the cutting start point)

G98(G84/G88)_ ;

(Second figure specification)

(nth figure specification)

G80M(Milling axis stop command P9876);

* Block (C) is output when bit 5 (MTM) of parameter No. 9846 is

set to 1 and a value is set for parameter No. 9088.
