B-63344EN/02 SUPPLEMENT 3.USEFUL FUNCTIONS FOR MACHINING PROCESSES

- 191 -

3.4 AUTOMATIC DIVISION OF TAUGHT-IN BLOCKS IN

GUIDANCE CUTTING

In guidance cutting, a cutting motion whose end point is the tool

position when a teach-in soft-key ([CUT]/[RAPID]) is pressed is

stored as a motion block.

Each motion can also be stored as a block according to the following

conditions by parameter setting:

- Switching between approach cutting and along cutting

- Direction of cutting in the handle or jog feed mode

- Axis along which the tool moves in the handle or jog feed mode

When soft-key [CUT] is pressed, all cutting motions stored as

separate blocks are taught as cutting feed (G01, G02, or G03).

When soft-key [RAPID] is pressed, they are taught as rapid traverse

(G00).

Up to 30 blocks of motions can be stored until the teach-in soft-key is

pressed.

When this function is enabled, if the tool is moved simultaneously

along two axes in the handle or jog feed mode, large blocks are stored

at a time. Always move the tool along only one axis.

NOTE

1 To use automatic division of taught-in cutting

motions, set bit 1 (TCA) of parameter No. 9762 to

2 For auxiliary function teach-in, up to eight blocks of

motions can continuously be stored, regardless of

whether the above parameter is set.

3 The same block may be taught as multiple

continuous blocks by handwheel operation. In this

case, delete unnecessary blocks.
