B-63344EN/02 APPENDIX C.DYNAMIC GRAPHIC DISPLAY FOR NC PROGRAMS

- 301 -

C.4 DYNAMIC GRAPHIC COMMANDS

To draw the blank to be machined or tool in machining simulation for

NC programs, input the following dedicated NC commands in the NC

program.

(1) Blank figure

G10 P90054 X(Xs) Z(Zs) ;

Start of registration of a blank figure. Xs and Zs indicate the

drawing start point of the blank.

G10 P90001 X(Xn) Z(Zn) ;

Line for the blank figure. Xn and Zn indicate the end point of the

line.

: (Specify the lines required for drawing the blank figure.)

G10 P90050 ;

End of registration of the blank figure

NOTE

If no blank figure data is input, the blank figure

specified immediately before drawing, including

that specified with MANUAL GUIDE machining

simulation, is drawn.

(2) Tool figure

For all tools used in the currently selected NC program, register tool

figure data at the beginning of the NC program as shown below:

G10 P90051 X(Xt) Z(Zt) Q(Gn) ;

Start of registration of the tool figure having graphic registration

number Gn. Xt and Zt indicate the tool tip position. Gn indicates

the graphic registration number of the tool (1 to 16).

G10 P90001 X(Xtn) Z(Ztn) ;

Line for the tool tip figure for graphic registration number Gn.

Xn and Zn indicate the end point of the line. (tool tip figure is

closed area specified the maximum 4 points)

: (Specify the lines required for drawing the tool tip figure.)

G10 P09000 X(Xss) Z(Zss) ;

Start point of the tool shank figure for graphic registration

number Gn(Xss/Zss)

G10 P90001 X(Xsn) Z(Zsn) ;

Line for the tool shank figure for graphic registration number

Xsn and Zsn indicate the end point of the line (up to six tool

shanks).

: (Specify the lines required for the tool shank figure.)
