A.PARAMETERS APPENDIX B-63344EN/02

- 264 -

#7 #6 #5 #4 #3 #2 #1 #0

9773 TRT MDL TCD GRO

GRO 1 : Data for graphic drawing is not outputted at NC format

program conversion.

0 : Data for graphic drawing is outputted at the above case.

TCD 1 : Sub program is called instead of T-code output.

0 : T-code is outputted.

< Related parameter : No.9778#7bit(CLT) >

MDL 1 : At NC format program conversion, a continuous state G code

(01 group) and F code are not outputted if they are the same as

those in the previous block.

0 : The above G code and F code are outputted always.

TRT 1 : When the tool is first move to the tool change position after

machining is started, it moves along the Z-axis then along the X-

axis.

0 : When the tool is first moved to the tool change position after

machining is started, it moves first along the X-axis then along

the Z-axis.

#7 #6 #5 #4 #3 #2 #1 #0

9774 T0O M1O 28O MLT MLS

MLS 1 : The specified M code (parameter No. 9876) is output to stop the

milling axis or change the direction of its rotation.

0 : When the direction of rotation of the milling axis changes, the M

code for stopping the axis is not output.

MLT 1 : To rotate the milling axis in the forward or reverse direction, the

specified M code (parameter No. 9877 or 9878) is output.

0 : M03 or M04 is output in the above case.

28O 1 : At the end of the program, T0 and G28 are not outputted.

0 : T0 and G28 are outputted automatically at the above case.

M1O 1 : M01 is output after the tool returns to the tool-change position at

the end of each process.

When using soft-key [PROCESS] on the animation screen,

always set M1O to 1.

0 : M01 is not outputted at the above case.

T0O 1 : T0 is outputted immediately before a return to the tool change

position (G30).

0 : T0 is not outputted at the above case.

#7 #6 #5 #4 #3 #2 #1 #0

9775

All of these bits must be set to 0
