6.RETHREADING SUPPLEMENT B-63344EN/02

- 250 -

(6) Teach the thread position to synchronize the tool feed with the

thread.

Before this operation, at least START X and START Y must be

set for the figure.

- Touch the tool on the bottom of the thread to be rethreaded.

- Press soft-key [SYNC P].

At this time, angular displacement Q for synchronization

with the thread described above is calculated and the

calculation result and taught position are displayed as

follows:

SHIFT = ←Calculation result Q

TYPE =

METHOD = REPAIR

ANGL =

LEAD =

START X =

START Z =

END X =

END Z =

SHIFT OFS = ←Amount of accumulation during acceleration Qp

SYNC POS = ←Taught thread position

If threading is executed before soft-key [SYNC P] is pressed,

macro alarm, "3001 CHECK PROCESS DATA," is issued.

(7) Manually remove the tool from the thread and move it to a safe

position at which cutting can be started. Then, press soft-key

[CAN OR] to cancel spindle orientation.

When soft-key [CAN OR] is pressed, the M code for canceling

orientation set for parameter No. 4961 is output. If the tool is not

at the distance specified for parameter No. 9843 from the thread,

the warning message, "MOVE TOOL AWAY FROM

THREAD," is displayed.

(8) Press soft-key [EXEC] or the [START] button on the machine

operator's panel to execute rethreading.

When rethreading is selected, process data "CUT TIMES" is

automatically set to 1. For this reason, rethreading is performed

only once in ordinary cases. The operator can change the value

set for "CUT TIMES/CUT AMUNT", however. When the value

is changed, rethreading is executed according to the specified

value.

To use this function, the parameter 9848 bit 7 (TRP) must be set

to 1.
