11.OUTPUTTING / INPUTTING MACHINING PROGRAMS OPERATION B-63344EN/02

- 94 -

11.2 INPUTTING MACHINING PROGRAMS

1) Push RESET key on a LCD/MDI keyboard.

2) Push [PROGRM] on an initial screen, then program list window

appears.

3) By pushing a right end soft-key [+], the following soft-keys

appears.

4) Using numeric keys, enter the number of the file containing the

machining program to be read and push a [READ]. Reading of

the machining program is started.

5) If the input equipment is other than the FANUC Handy File or

its equivalent one, input 1 as a file number always.

6) When reading of the machining program starts, the “INPUT”

message blinks at the bottom of the screen. It continues to flash

until the operation ends.

READPUNCHALL-PN
