C.DYNAMIC GRAPHIC DISPLAY FOR NC PROGRAMS APPENDIX B-63344EN/02

- 298 -

C.2 OPERATION (MACHINING SIMULATION)

1) Disable the MANUAL GUIDE according to the instructions in

the manual supplied by the machine tool builder. In ordinary

cases, turn the MANUAL GUIDE selection switch on the

machine operator's panel off.

2) Select an NC program for machining simulation according to the

instructions in the NC function operator's manual. Also, select

the memory operation mode.

3) Press function button GRAPH to display the machining

simulation screen.

4) Press soft-key [G.PRM] to display the graphic parameter screen.

On this screen, set required data. In ordinary cases, only the

following data items are required. (For details of other data items,

refer to the explanation of the graphic function in the NC

function operator's manual.)

WORK LENGTH W:

Length of the blank to be machined

(Valid data range 0 to 99999999,

Increment system 0.001mm/0.0001inch)

WORK DIAMETER D :

Diameter of the blank to be machined (The valid data range and

increment system are the same as for WORK LENGTH.)

GRAPHIC MODE M :

Drawing format. Be sure to set a value between 1 and 3.

1 = Blank (cross section) and tool path

2 = Animated drawing of cutting the blank (cross section) with

the tool

3 = Animated drawing of cutting the blank (cross section) with

the tool and tool path

In ordinary cases, set 1.

NOTE

Graphic parameters WORK LENGTH and WORK

DIAMETER are used only for determining the

drawing scaling factor and position and not used for

drawing the blank figure.

To draw the blank figure, input dynamic commands

described in Section C.4 additionally.

5) Press soft-key [GRAPH] to display the machining simulation

screen. Press soft-key [(OPRT)] to display the following soft-

keys. Use these soft-keys for required operation.

SPEED UP :

Increases the machining simulation speed. (Valid data range: 0

to 500) In ordinary cases, set 500 (maximum speed).

SPEED DOWN :

Reduces the machining simulation speed.
