4.GUIDANCE CUTTING OPERATIONSOPERATION B-63344EN/02

- 36 -

4.4 EDITING TAUGHT-IN BLOCKS

Taught-in “Auxiliary Function Block”, “Rapid Traverse Block” and

“Cutting Motion Block” can be displayed in a figure data window as

described in 4.3. And an operator can edit these blocks too.

4.4.1 Figure Data Window

By using 4-directional cursor keys ↑ ↓ → ← on a LCD/MDI unit, a

cursor in a figure data window can be moved for pointing the data

word of taught-in blocks.

As described above, at the time that a cursor is in a figure data

window, an operator can carry out a guidance cutting using guidance

handwheel, and teach-in these cutting motions into CNC for later

playback machining.

In this figure data window, taught-in cutting motion blocks are

displayed, and an operator can edit the contents of them.

By pushing a cursor key ↑ or ↓, the contents of figure data window

are shifted up and down, and an operator can see the whole blocks.

TOOL KIND =

TOOL DATA =

G97 S300 ;

M03 ;

;

G1 X100. Z20. F0.5 ;

G1 X90, Z25. F0.5 ;

Figure Data

Window

Cursor

T101
