B-63354EN/04 III. SETTING 6.DATA SERVER FUNCTIONS FOR THE 15i

- -89

6.1 PRECAUTIONS TO BE OBSERVED WHEN USING THE

DATA SERVER FUNCTIONS FOR THE FIRST TIME

CAUTION

1 When the data server board is used for the first time,

format the hard disk, set the appropriate parameters,

and turn the power off then on again. If the data

server functions are used without first performing

these operations, normal operation cannot be

guaranteed.

2 When Ethernet FTP communication is carried out for

the first time, consult with your company's network

administrator to determine the network addresses

and other settings. Then, conduct a communications

test.

If incorrect network addresses and other settings are

set, communication and other faults may adversely

affect the entire network.

Particularly, if a duplicate IP address is set, the data

server causes communication errors intermittently.

This may result in a CNC's system error. To check

whether the IP address duplicates any one already in

use, see "Checking IP addresses for duplication" in

Appendix A.4, "Checking Communication."

3 Never turn off the power to the CNC while the hard

disk is being accessed (a data server function service

is being executed). Otherwise, the data saved on the

hard disk may be destroyed.

4 Never turn off the power to the CNC while using the

functions, especially the FTP server functions.

5 To guard against hard disk failure, back up the files

on the hard disk of the host computer.

NOTE

1 The following option parameter is needed when the

data server functions are used:

Series15i-MA A02B-0261-J827

2 The following options are required to use buffer mode

for data server features:

Series15i-MA A02B-0261-J697

3 Only one FTP client can be connected to one CNC by

the data server functions. One CNC can be

connected to only one FTP server.
