4.16i/18i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -140
4.2.4 Copying a Hard Disk File
Copy files stored in the data server board built-in hard disk.
Procedure
1 Display the Hard Disk File Dir screen.
2 Press soft key [(OPRT)].
3 Press soft key [F COPY].
4 Enter the number or name of the copy source file and the name of
the copy destination file using the MDI keys.
[Input format]
<copy-source-file-number>, <copy-destination-file-name>
or <copy-source-file-name>, <copy-destination-file-name>
5 Press soft key [EXEC].
6 During the copy operation, "COPY" blinks in the lower-right part
of the screen.
NOTE
1 The copy source file number or name must be
separated from the copy destination file name by a
comma (,).
2 An error occurs if the name of a file stored on the data
server board built-in hard disk is specified as the copy
destination file name.
3 Specifying a copy source file with its file number is
valid only for those files displayed on the Hard Disk
File Dir screen.
