B-63354EN/04 IV. OPERATION 4.16i/18i DATA SERVER FUNCTIONS

- -171

DNC operation by a subprogram call (M198) in the FTP mode

Procedure

1 Place the CNC in MEM mode.

2 Select the host number for the host holding an NC program to be

called by a subprogram according to the procedure described in

Subsection 4.9.2, "Reconnecting the Host," to display the Host

File Directory screen.

3 Press soft key [(OPRT)].

4 Press soft key [M198 H].

5 Press soft key [EXEC]. The host number of the currently

connected host is displayed to the right of "M198 CONNECT

HOST" on the screen.

6 An automatic operation is performed based on the NC program

containing the M198 command.

NOTE

1 DNC operation by a subprogram call (M198) cannot

be executed simultaneously with NC program input,

NC program output, or DNC operation.

2 The file name of the subprogram to be called by DNC

operation by a subprogram call (M198) must be

Oxxxx.

3 Assume that there is a subprogram called by DNC

operation by a subprogram call (M198) and that a

subprogram call is further executed in this

subprogram. If the subprogram to be called exists on

the tape memory, the subprogram can be executed.

If, however, the subprogram exists on the hard disk, it

cannot be executed as a subprogram.

4 When viewed from the CNC, the data server function

is handled in the same way as for other input/output

equipment. Therefore, the subprogram call

restrictions are the same as those for other

input/output equipment.

5 Multipath control can be performed on DNC

operations by a subprogram call (M198) on multiple

paths at a time; however, the programs must be in

the same work directory.
