Ethernet/Data Server Board Operators manual Page 427

Operators manual
Power Mate
i
-MODEL D/H
Setting/punch operation for Ethernet Data
with DPL/MDI and DPL/MDI operation
package Specification
B-63354EN/04-01
EDIT DATE DESI
DESCRIPTION
10 /12
CUST.
SHEET
TITLE
DRAW.NO.
Data no
# 7 # 6 # 5 # 4 # 3 # 2 # 1 # 0
0727 ROUT TRN
(Data type): Bit
TRN : This bit is used for sending the parameters from No.707 to No.726 to the
Ethernet board. If the parameters from No.707 to No.725 are accepted in
the Ethernet board, the status of this bit is 1 and will not be changed.
But if sent parameters are not accepted, this bit will be changed to 0.
Then please correct parameter’s data and set again.
0: Ethernet board does not accept parameters.
1: Ethernet board accepts parameters
ROUT : This bit specifies whether parameters of router IP address from No.720
to No.723 are used or not.
0: not use.
1: use.
When there is not a router on the network or you do not need to use
router IP address, you have to set 0 to this bit.
