A.TROUBLESHOOTING APPENDIX B-63354EN/04

- 374 -

A.3 CHECKING SETTINGS

The following describes how to check the minimum settings needed for

communications.

NOTE

For details on IP addresses, subnet mask and other

set values, consult with the network administrator.

• Checking settings on the Ethernet board

1) Make sure that the MAC address of the Ethernet board is

displayed.

• This address is appended to each board before shipment

from the factory, and is automatically displayed in the

Setting screen. This address need not be set by the user.

For details, see "IV Operation Manual, 1.4 Setting

Screen."

2) Make sure that the IP address is set.

3) Make sure that the subnet mask is set.

4) When a router is used, make sure that the router IP address is

set.

• Checking settings on the personal computer

1) Make sure that the IP address is set.

2) Make sure that the subnet mask is set.

3) When a router is used, make sure that the router IP address is

set.

• For details on how to set, see "IV. Operation."
