i DATA SERVER FUNCTIONS IV. OPERATION B-63354EN/04
- -224
•
••
• MPUT
Transfers two or more files from the data server board built-in hard disk
to the host computer built-in hard disk. Wild cards (*, ?) can be used to
specify file names.
•
••
• PUT LIST
Transfers files from the data server board built-in hard disk to the host
computer built-in hard disk according to the list file.
•
••
• DEL LIST
Deletes files from the data server board built-in hard disk according to
the list file.
•
••
• COPY FILE
Copies a file from the data server board built-in hard disk.
•
••
• DEL FILE
Deletes a file from the data server board built-in hard disk.
•
••
• CHANGE FILE NAME
Changes a file name on the data server board built-in hard disk.
•
••
• SRCH FILE
Searches the data server board built-in hard disk for a file by using a file
number or name.
•
••
• MAKE DIR
Creates the directory on the data server board built-in hard disk.
•
••
• DEL DIR
Deletes a directory from the data server board built-in hard disk.
•
••
• MOVE DIR
Moves the work directory on the data server board built-in hard disk.
•
••
• REDRAW SCRN
Updates the Hard Disk File Directory screen.
•
••
• CHANGE SCRN
Switches between normal display and detailed display.
•
••
• SPECIAL CHAR
Enables highly-used characters to be entered when not supported by the
MDI keys.
•
••
• CAPS LOCK
Switches the alphabetic character input mode (uppercase letter input
mode and lowercase letter input mode).
•
••
• HOST DIR.
Switches the current screen to the Host Directory screen.
NOTE
If the CNC software series is the F001 or F601, the
following keys cannot be used:
- M198 DIR SET
- MAKE DIR
- DELETEDIR
- MOVE DIR
